Xournal++ 是一款支持 PDF 注释的手写记事软件，采用 C++ 语言和 GTK3 编写，支持 Linux、macOS 和 Windows，支持 Wacom Tablets 等设备的笔输入，开源免费。
- PDF 批注。
- 支持以 SVG、PNG、PDF 等格式导出。
- 支持以 Lua 编写的插件。
This is a new major version of Xournal++ with many new features, improvements, and bug fixes thanks to over one year's worth of contributions from the community.
- Breaking changes:
- Xournal++ now follows the XDG Base Directory Specification (#1101, #1384). The configuration files will now be stored in an appropriate platform-specific user data folder. Old configuration files will be copied automatically if the new user data folder does not exist.
- For users that have non-default DPI settings, text elements in old documents may be displayed with incorrect sizes/positions. A new plugin is included to fix the positioning of these text elements. See the relevant bug in the "Text tool" section below.
- The old input system has been removed, which may affect some users.
- Windows: The installer has been updated, fixing many issues such as: incorrectly set up registry keys, missing uninstaller entry, missing entries in Open With context menu in Explorer, missing icons, etc. (#2606, #2585, #2387, #2141, #2036, #1903, #2666, #3215). When upgrading from 1.0.18, you must not run the uninstaller; instead, run the updated installer, which will clean up files from the old install and fix the registry key entries. If you are downgrading from 1.1.0 to 1.0.18 or older, you must run the uninstaller first.
- Linux: Support for Ubuntu 16.04 (and older distros) has been dropped. Please use a distro from 2018 or later, such as Ubuntu 18.04 or Debian Buster. The dependency versions have been updated accordingly.
- Linux: The thumbnailer program has been renamed from
xournalpp-thumbnailerin order to fix tab completion (#1752).
- Linux: Xournal++ now has a hard dependency on
librsvg. This should not affect end-users, only maintainers and packagers.
- The code has been updated to use C++17 (#1485) and must now be compiled using a supported compiler version, such as GCC 7 or Clang 5 (or newer).
- MacOS: Dropped support for macOS High Sierra; minimal version is now Catalina (#2989)
- Document viewing
- Changed page selection system to now select the current page during scrolling (#1613, #1184).
- Improved page load performance and memory consumption with new page preload mechanism (#2603).
- Fixed a bug where scrolling would not work with zoom fit enabled until the zoom level changes (#2541).
- Fixed some bugs that prevented documents from being displayed on ARM and 32-bit devices (#2576).
- Fixed vim-style
hjlkkeybindings being inconsistent with the arrow keys (#2712).
- Added a shortcut for the default tool (#2872) and changed shortcuts for page deletion and layer navigation (#2766)
- Fixed various issues related to zooming and scrolling (#2435, #2743, #2023, #1830, #2821)
- Fixed zoom slider tick marks being set to the wrong values when DPI calibration setting is different from the default (#2923)
- Fixed a freeze caused by scrolling between pages of different size (#2770, #3099).
- Document export
- Added a "progressive mode" option to PDF file export dialog. This will render layers from bottom to top, exporting a new page every time a layer is rendered (#2589, #2609).
- Simplified background rendering to improve compatibility of exported SVGs (#2598).
- Made line spacing equal in export and on view when pango version >= 1.48.5 is available (#2182)
- Updated the Cairo version on Windows to fix a bug that created corrupt PDF files on export (#2871)
- Fixed a crash that occurs when closing the application before export finishes (#3159).
- Sidebar preview panel
- Added new "Layerstack Preview" tab that shows all layers up to the current layer (#2795).
- Changed sidebar colors to be dark when using a dark theme (#2726).
- Changed layer previews to only show background in background layer (#2674)
- Moved close button from the bottom to the top to improve usability (#2727).
- Fixed button tooltips not reflecting the page/layer tabs (#2776).
- Fixed a bug where the buttons would be enabled/disabled inconsistently (#2776).
- Audio playback
- Added seeking functionality during playback (#1520)
- Fixed crashes caused by race conditions in the audio system
- Fixed bug where gaps in the audio stream could appear while recording
- Added an error message popup which displays when a recording fails to load or play (#1573)
- Input System
- Removed the old input system and touch workaround, both of which have been deprecated (#2308).
- Added a
Mouse+Keyboarddevice class for handling e.g. wireless USB mouse/keyboard receivers (#1769, #1785).
- Added Preference settings for minimum pressure level and pressure multiplier (#2622).
- Added an experimental stroke smoothing / input stabilization feature (#2512, #2856, #2863).
- Added a touchpad pinch gesture for zooming (#2651).
- Added a Preferences setting to ignore the first few pen input events when starting a new stroke (#1854).
- Reimplemented zoom gestures for better compatibility (#1528)
- Improved tool handling (#2339)
- Fixed a bug where the touchscreen could not be used to pan and zoom when touch drawing is enabled (#2435).
- Fixed a bug where two-finger zoom would be triggered even when zoom gestures are disabled (#2510).
- Fixed touch drawing not working with the pen tool (#2123).
- LaTeX tool
- Reworked LaTeX tool implementation (#1952).
- Added a new tab in the Preferences window for LaTeX configuration.
- Added a
global template filesetting for custom LaTeX template files to be used when rendering LaTeX formulas (#1188).
- Added a button in the Preferences window for testing LaTeX setup.
- Fixed a bug where closing the dialog before the initial render would crash the application (#2728, #2798).
- Fixed a bug where line breaks would not be saved correctly (#2849).
- Windows: Fixed a bug where long user names would break the LaTeX tool (#3046).
- Spline tool
- Added cubic splines as a drawing tool (#1688, #1798, #1861).
- Click to add anchor points (knots) and drag to create non-trivial tangents. Backspace key, arrow keys, s and Shift+s allow to delete/modifiy the last set knot/its tangent. Escape key and double click exit the spline drawing mode.
- Added snapping for vertical space (#2011)
- Added snapping for moving and resizing selections (#1972, #2011)
- Added snapping for recognized shapes (optional setting; #2011)
- Added a Preferences settings to preserve line width while resizing a selection (#2011)
- Added a Preferences setting to change the snap grid size (#1920).
- Fixed a bug in the grid snapping tolerance (#2779).
- Added ability to mirror selected elements when scaling in a negative direction (#2723).
Edit > Arrangemenu items and the corresponding actions for rearranging selected elements (#2794).
- Changed element selection to not automatically rearrange items (#1680). Instead, rearranging must be performed with the newly added menu entries.
- Fixed some bugs where selections would not be copied correctly (#2277, #2090, #2733) and would cause strokes to become invalid/missing when saving (#2857, #2464).
- Fixed a bug in the Select Object algorithm (#2478)
- Pen and eraser tools
- Added Preferences settings to configure the radius, color, and border of the cursor highlight when
Highlight cursor positionis enabled (#1891, #1898).
- Added a new "no cursor" cursor type and changed "Big pen" checkbox in Preferences into a combo box (#2111).
- Renamed "fill transparency" to "fill opacity" to avoid confusion (#2590).
- Added thick/thin settings to default tool preferences (#2611).
- Added ability to change line styles of existing strokes (#2641).
- Changed name of "Draw Circle" to "Draw Ellipse" (#2708).
- Changed name of "Ruler" to "Draw Line" (#2959).
- Improved circle drawing controls (#2707).
- Improved the accuracy of the eraser tool (#1818).
- Changed pen/highlighter cursor to be in the shape of a circle with the approximate stroke size (#1945, #1513).
- Fixed a cursor update bug (#1954).
- Fixed strange behavior of color switches when temporarily using the eraser (#2004, #1546, #1712).
- Added Preferences settings to configure the radius, color, and border of the cursor highlight when
- Text tool
- Added support for text edit blinking to be enabled/disabled through standard GTK configuration settings (#2170).
- Fixed several serious bugs and user experience issues with IME pre-edit strings (#2789, #2788, #2826, #2851).
- Fixed a bug where the font button would not be updated when editing a text field (#2620).
- Fixed a bug where text elements would not be displayed at the correct positions when an image is used as the page background (#2725).
- Fixed a bug where text would be displayed with an incorrect size when DPI is set to a non-default value. A plugin for migrating documents with wrong font sizes has been added (#2724).
- Fixed a bug where selected text would be highlighted incorrectly (#3131).
- Added a print button to the default toolbar (#1921).
- Added a menu toggle item for showing/hiding the toolbar, bound to F9 (#2112).
- Added a vertical mode for the pagespinner tool (#2624).
- Added color indicators to toolbars when customizing the toolbars (#2726).
- Improved appearance of the floating toolbar (#2726).
- Fixed a crash that occurs when the application is closed with the toolbar customization dialog open (#1189).
- Fixed multiple bugs involving the toolbar customizer (#2860).
- Extended plugin API with many new features and functions, including page and layer operations (#2406, #2950).
- Added a Lua plugin for taking a screenshot and saving it to a file (#2086, #2787).
- Added a Lua plugin for cycling though a color list (#1835, #2251).
- Added Lua plugin support for MacOS (#2986)
- Allow using the system Lua package path (#2968)
- Paper backgrounds
- Added an isometric paper background type (#1994).
- Changed background types to use lighter line colors when a dark background is set. The colors can be set in
- Fixed the confusing behavior of the
Apply to current/all pagesbuttons used to change the page backgrounds (#2730).
- Fixed cloned background images not loading correctly (#3170).
- Packaging changes
- AppImage: Fixed AppImages not running on more recent Linux distros (#2600).
- Linux: Fixed an issue with dock icons not appearing correctly in some desktop environments (#2881, #1791).
- Debian packages: added man pages (#2701)
lua-lgipackage has been added to the list of
Recommendeddependencies. It is useful for creating GUI in Lua plugins.
- Streamlined and updated package metadata (#3094).
- Updated author information and About dialog appearance (#3209)
- New action icons (#3154) and new application icon (#2557).
- Changed the error dialog for missing PDF backgrounds to display the full path of the missing PDF (#3140).
- Changed default key binding of middle mouse button from nothing to hand tool (#3121).
- Changed the
Help > Helpmenu item to point to the new website www.xournalpp.github.io, which replaces the User Manual wiki.
- Added a setting in the Preferences window for selecting the language (#2188). Simplified language translation file names (#3166, #3201).
- Added a feature to allow the user to modify the locale directory via the TEXTDOMAINDIR environment variable (#2600, #2845).
- Added support for more export options in command line and GUI (#2449)
- Added a command line option to create a xopp file (#1919).
- Added the
Journal > Rename Layermenu entry to rename layers (#2321).
- Added the
Journal > Append New PDF Pagesmenu entry to append PDF pages that are not in the current annotation file (#2146)
- Improved look of the Preferences window (#2592).
- Improved Print Dialog verbosity and error handling (#3002)
- Fixed a bug where the
Autoloading Journalsoption would only autoload annotation files with
.pdf.xojextensions. (#2911, #3217).
- Fixed bugs in element cloning, which previously could have caused elements to become invalid (#2733, #2720, #2464).
- Fixed a bug where the thumbnailer would not correctly render previews in file managers that sandbox their thumbnailers (#2738).
- Fixed a bug where some error message dialogs would not display the message correctly (#3214).
- Fixed keyboard shortcuts not working when the menubar is hidden (#2324)
- Fixed the undo operation for moving objects across page borders (#3068)
- Updated the translation files.
- Non-visible refactoring and code cleanup (#1279, #2150, #1944, #2199, #2213, #2252, etc.)
- MacOS: Fixed the startup crash on BigSur and removed the integration of Xournal++ into the Mac Menu Bar (#2836, #2976)
- Windows: Fixed a crash that occurs when closing the application (#2218).
